UTV : Lucky T9
LOW VOLTAGE SWITCHGEAR
| Ref# | Part | ||
|---|---|---|---|
| 1 |
DA4500010
Winch Windlass
|
||
| 2 |
DA3721010 Horn Assembly |
||
| 3 |
DA3703022
Battery Hold Down Rod
|
||
| 4 |
DA3703010
Battery Hold Down Plate
|
||
| 5 |
KL2120100
12V Battery Assembly
|
||
| 6 |
DC3774010
One Click Start Module Set (Includes Key Fob)
|
||
| 7 |
DC3774020
One Click Start Switch (Internal Use Only)
|
||
| 8 |
DC3774030
Solenoid (Internal Use Only)
|
||
| 9 |
DC2107030
USB Charging Port
|
||
| 10, 11 |
DA7913001
T-Box Host Kit (with DA7913201)
|
||
| 12 |
DA3820211
Vehicle Display
|
||
| 13 |
DC3792050 Winch Switch |
||
| 14 |
DC3792030
Headlight Switch
|
||
| 15 |
KL2146110 Electronic Shifter |
||
| 16 |
DC2102100
Hall-Type Electronic Throttle
|
||
| 17 |
DC4010010
Chassis Wiring Harness
|
||
| 18 |
DA4134010
Rear Combination Light
|
||
| 19 |
DA3820220
Backup Camera
|
||
| 20 |
DA4101020
Upper LED Light Bar
|
||
| 21 |
DA4101050
Lower LED Light Bar
|
||
| 22 |
DA4500012
Winch Relay
|
||
| 23 |
DA4500011
Winch Fairlead
|
